DTII(A) drive pulleys manufactured to the required torque, belt load, shaft, bearing and installation interfaces.
Junxin manufactures DTII(A) drive pulleys that transfer torque from the drive unit to the conveyor belt. Pulley diameter, face width, shaft geometry, bearing arrangement and surface configuration are selected together from the required torque, resultant belt load and conveyor operating duty.
The DTII(A) range supports multiple diameter, torque, load and bearing combinations for new conveyors and replacement projects. Existing drawings, shaft and bearing details, or measured installation dimensions can be reviewed before the production configuration is approved.
Available manufacturing ranges and configuration values are shown below. Final production data is confirmed for each order.
| Specification | Value |
|---|---|
| DTII(A) Drive Pulley Specification Range250 mm | Torque 0.63 kN·m · Load 15 kN |
| DTII(A) Drive Pulley Specification Range315 mm | Torque 0.63–1.25 kN·m · Load 12–25 kN |
| DTII(A) Drive Pulley Specification Range400 mm | Torque 1.0–2.5 kN·m · Load 15–35 kN |
| DTII(A) Drive Pulley Specification Range500 mm | Torque 1.6–6.3 kN·m · Load 30–75 kN |
| DTII(A) Drive Pulley Specification Range630 mm | Torque 4.1–20 kN·m · Load 40–100 kN |
| DTII(A) Drive Pulley Specification Range800 mm | Torque 7–66 kN·m · Load 50–520 kN |
| DTII(A) Drive Pulley Specification Range1000 mm | Torque 12–120 kN·m · Load 80–800 kN |
| DTII(A) Drive Pulley Specification Range1250 mm | Torque 40–160 kN·m · Load 260–1200 kN |
| DTII(A) Drive Pulley Specification Range1400 mm | Torque 66–160 kN·m · Load 450–1200 kN |
| DTII(A) Drive Pulley Specification Range1600 mm | Torque 80–160 kN·m · Load 520–1200 kN |
| DTII(A) Drive Pulley Specification Range1800 mm | Torque 120–160 kN·m · Load 800–1200 kN |
A simplified component view showing the principal areas used to transfer torque and connect the pulley to the drive and bearing arrangement.
Send us your drawing, measured dimensions, sample reference or application data. Junxin will review the manufacturing configuration and installation interfaces before quotation.
Junxin checks welding, machining dimensions, shaft and bearing interfaces, pulley runout and surface condition against the approved drawing before dispatch.
Please share belt width, pulley diameter and face width, shaft drawing or bearing details, drive power or torque, belt tension and lagging requirement.
Yes. Drawing-based manufacturing is supported after dimensions, materials, tolerances and inspection requirements are reviewed.
